Pulsar Turbo Systems

PSR 7782G Dual Ball Bearing Turbocharger HP Rating 1500

PSR 7782G Dual Ball Bearing Turbocharger HP Rating 1500

$2,544.35
$2,544.35
Sale Sold out
Compressor Housing Options
Turbine Housing Options

Description

Dual ceramic ball bearing system provides optimal turbo response &
better durability by reducing the shaft-motion

13 Blade G-Aero billet compressor wheel with extended tapered tip technology

9 Blade G-Aero Inconel 713c turbine wheel

Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor and pressure ports

Water fittings included with the super core

8 Options in Turbine Housing

HP rated at 1500HP at flywheel

Installation Hardware: 3” flange kit for Comp. Outlet, T4 Gasket/3” flange kit for Turb. Inlet, 3.5”/4” flange kit for Turb. Outlet and oil Drain Fitting kit are included by default

Oil Feed Fitting needs to be bought separately

Specifications

  • Compressor Wheel: 76.6*109.2mm
  • Turbine Wheel: 89*81.6mm
  • Compressor Inlet: 5″ Hose
  • Compressor Outlet: 3″ V-Band
  • Turbine Inlet: 3″ V-Band/T4 open/ T4 divided
  • Water Ports: -6AN
  • Oil Feed: Flange Required (Recommended size: -4AN Std T4 Flange Non-Restricted)
  • Oil Drain: -12AN (O-Ring sealed Flange Kit Incl’)

Turbine housing option:

  • T4(Divided) inlet, Vband outlet (fits 4″ OD tubing), 1.01 A/R
  • T4(Open) inlet, Vband outlet (fits 3.5″ OD tubing), 1.15 A/R
  • T4(Divided) inlet, Vband outlet (fits 4″ OD tubing), 0.95A/R
  • T4(Divided) inlet, Vband outlet (fits 3.5″ OD tubing), 1.15 A/R
  • T4(Divided) inlet, Vband outlet (fits 4″ OD tubing), 1.28 A/R
  • T4(Divided) inlet, Vband outlet (fits 4″ OD tubing), 1.44 A/R
  • Vband inlet (fits 3″ OD tubing) and Vband outlet (fits 3.5″ OD tubing), 1.01 A/R
  • Vband inlet (fits 3″ OD tubing) and Vband outlet (fits 3.5″ OD tubing), 1.15 A/R
  • Vband inlet (fits 3″ OD tubing) and Vband outlet (fits 3.5″ OD tubing), 1.28 A/R
